Subcard-02
Minimum Order Quantity
100
Description
PCB Dimension: 120*40mm, slim form factor for built‑in installation inside commercial displays and interactive all‑in‑one devices.
-
Standard OPS‑C Gold‑finger Connector Fully compliant with OPS‑C specification. Integrated OPS Prot and DET_PWR1 detection pins realize power handshake and signal identification between OPS compute module and display panel. Compatible with mainstream RK ARM‑based and X86 OPS modules.
-
Versatile Expansion Pin Headers for Customization Exposed pin terminals for ONEKEY power control, TV_CTRL display control, RX/TX serial debug port, SW function switch and DET_PWR detection signal. Supports one‑key power‑on, equipment status monitoring and secondary development, ideal for OEM & ODM projects.
-
Comprehensive I/O & Audio‑video Interfaces Equipped with HDMI port, multiple USB3.0 high‑speed ports. Independent MIC input and LINE‑OUT audio output are available. On‑board STATUS and DET_LED indicator LEDs offer real‑time visual working status feedback, perfectly matching requirements of conference panels and digital signage.
- Industrial‑grade Circuit Design
- Optimized for Commercial Display Applications
Technical Parameters
Size
120*40mm
USB
1*USB3.0; 2*USB2.0
Display
HDMI*1
