H610M ITX Gaming PC
Model: H610M ITX DIY Gaming PC
ITX MB Features
- High Scalability
Abundant PCIe/PCI expansion slots and multi-storage interfaces, ideal for industrial workstations, servers and high-performance computing applications.
- Flexible Networking
Integrated WIFI and 5G+SIM module slots, supporting wired Ethernet, Wi-Fi and 4G/5G cellular connectivity for diverse industrial IoT deployments.
- Rich Industrial I/O
Multiple COM ports, LPT print header and USB ports, ensuring full compatibility with legacy industrial peripherals (PLC, sensors, printers, etc.).
- Stability & Security
TPM hardware security module, robust power delivery and dual fan cooling design guarantee 24/7 stable operation in harsh industrial environments.
- Multi-Display Support
HDMI/EDP output interfaces, suitable for industrial control HMI, digital signage and multi-screen monitoring systems.
Full Product Specifications
| CPU Model | LGA 1700 socket for 12-14th Intel® Latest Desktop processors |
| Platform | Intel® |
| Cores / Threads | 20cores 28threads |
| Graphics | Intel® UHD Graphics 770 |
| Memory | DDR4 2666/ 3200MHz |
| Max Memory | 128GB |
| Storage | 1×M.2 SSD slot; 1×SATA3 ports |
| Storage Expansion | 1×MXM slot, 1x M.2 E Key |
| Interface Type | Quantity | Specification |
|---|---|---|
| LAN | 2 | 2x Intel I210,I219 1000M |
| USB | 12 | 6*USB3.2 Gen2 [最大支持Max Support：10Gbps ] 6*USB2.0 |
| Display | 3 | HDMI, DP, VGA |
| COM | 2 | 2x RS232/485/422 |
| Operating Temperature | -20 to 60 ℃ |
| Power Input | 500W |
| Power Consumption | 65-219W |
| Protection | Transparent Case with shinning fans |
| Dimensions | 305 × 244 mm |
| Weight | 1.2KG |
| Mounting Method |
Embedded
|
