Key Features
CPU
Support Intel® N100/ N95/ N150 N Series
Memory
LPDDR5 4800MHz
Storage
4*M.2 M Key 2280 solt Support NVMe/ SATA Protocol
Operating Temp
-20 to 60 ℃
Nas Mini PC
Affordable Level
Nas Mini PC N100
Model: Nas Mini PC N100
CE
FCC
RoHS
Features:
- 4‑Bay M.2 NVMe 2280 All‑Flash Storage Supports four NVMe 2280 SSDs, all‑flash design delivers ultra‑fast read‑write performance, no mechanical hard disk noise.
- Powerful X86 Processor Options Equipped with Intel N100 / i3‑N305 CPU, solid computing power for NAS, virtualization and light server tasks.
- Dual Intel 2.5G Ethernet Ports Dual 2.5G network ports for link aggregation, high‑speed file transfer, ideal for local area network data access.
- Rich Expansion Interfaces Dual USB3.2, dual HDMI video output; M.2 E‑Key slot reserved for WiFi‑7 module upgrade.
- Compact Pocket‑size Fanless Chassis Small form‑factor fanless cooling structure, low noise, high stability, suitable for long‑time 24/7 operation.
- Flexible Deployment Scenarios Perfect for home NAS, small‑business data storage, edge server, private cloud and media server applications.
MOQ: 100 units
Technical Specifications
Full Product Specifications
| CPU Model | Support Intel® N100/ N95/ N150 N Series |
| Platform | Intel® |
| Cores / Threads | 4cores 4threads |
| Graphics | Intel® UHD Graphics |
| Memory | LPDDR5 4800MHz |
| Max Memory | 16GB |
| Storage | 4*M.2 M Key 2280 solt Support NVMe/ SATA Protocol |
| Storage Expansion | 1*M.2 E Key 2230 solt |
| Interface Type | Quantity | Specification |
|---|---|---|
| LAN | 2 | 2x Intel i226 2.5G LAN |
| HDMI | 2 | 2x HDMI |
| USB | 2 | 2x USB3.2 |
| Operating Temperature | -20 to 60 ℃ |
| Power Input | DC12V 5-20.35V |
| Power Consumption | 8-15W |
| Protection | Alluminue Case |
| Dimensions | 100*100*60MM |
| Weight | 0.61KG |
| Mounting Method |
Wall Mount
VESA
|
