Key Features
CPU
Support Intel® N100/ N95/ N150 N Series
Memory
1*DDR5/4 4800/3200MHz
Storage
2*M.2 M Key 2280 solt Support NVMe/ SATA Protocol（Jumper Switch）+ 1*SATA 3.0 Interfaces
Operating Temp
-20 to 60 ℃
Industrial PC
Affordable Level
IPC DY35-N100
Model: IPC DY35-N100
CE
FCC
RoHS
-
Processor & Graphics
Equipped with Intel® N100/ N95/ N150 N Series. Integrated Intel® UHD Graphics, max dynamic frequency 1.2GHz.
-
Memory & Storage
- Single DDR5/4 SO-DIMM slots, maximum 16GB RAM
- 1×M.2 NVMe slot pre-installed with 512GB storage;
-
Dual 2.5G Ethernet
Dual Intel I225V 2.5G RJ45 ports. Supports Wake on LAN, timed boot, PXE diskless boot.
-
Rich Serial & I/O Interfaces
- 6×DB9 COM ports; COM1/COM2 configurable as RS232/422/485 via BIOS
- 4×USB3.0 + 4×USB2.0
- 1×HDMI1.4 (4096×2160@24Hz), 1×VGA (1920×1080@60Hz)
- MIC input, speaker output, power button, DC 12V power jack
- 8 GPIO pins (4 input + 4 output)
-
Dual Mini PCIE Expansion Slots
One slot for Wi-Fi/Bluetooth module; another for 3G/4G cellular modules.
-
Cooling
Fanless aluminum enclosure, low noise and low power consumption.
MOQ: 50 units
Technical Specifications
Full Product Specifications
| CPU Model | Support Intel® N100/ N95/ N150 N Series |
| Platform | Intel® |
| Cores / Threads | 4cores 4threads |
| Graphics | Intel® UHD Graphics |
| Memory | 1*DDR5/4 4800/3200MHz |
| Max Memory | 16GB |
| Storage | 2*M.2 M Key 2280 solt Support NVMe/ SATA Protocol（Jumper Switch）+ 1*SATA 3.0 Interfaces |
| Storage Expansion | 2x Mini PCIE: one slot for Wi-Fi/Bluetooth module; another for 3G/4G cellular modules. |
| Interface Type | Quantity | Specification |
|---|---|---|
| USB | 6 | 4*USB3.0, 2*USB2.0 |
| LAN | 2 | 2 x Intel I225V 2.5G RJ45 ports |
| Display Port | 1 | HDMI |
| COM | 6 | COM1/COM2 configurable as RS232/422/485 via BIOS |
| Operating Temperature | -20 to 60 ℃ |
| Power Input | 12V 7A 82W |
| Power Consumption | 45-115W |
| Protection | Air discharge ± 8 KV Class C ± 6 KV of grade B Contact discharge is ± 6 KV Class C ± 3 KV Grade B * Test of the whole machine under good grounding |
| Dimensions | 182*106*64.08MM |
| Weight | 1.8KG |
| Mounting Method |
Wall Mount
VESA
Embedded
|
| Dimension Drawing | structure-of-the-case.jpg |
